Fluke 301A+ Clamp Meter
The Fluke 301A+ Clamp Meter has a lightweight and compact body, which allows you to carry it around in your pocket. The slim and thin jaw can easily clamp onto tightly packed wires. The Fluke 301A+ tests current, voltage, resistance, continuity, frequency (voltage and current), capacitance, and diode, etc.. You can handle more testing needs with it.
key features :
-The body weighs only 132g and is 16mm thick, which is light and portable and can be fitted into a pocket
-The slim and thin jaw of only 10mm can easily clamp onto tightly packed wires
-400A AC range, 0.01A high resolution
-Tests voltage, resistance and continuity
-Tests current frequency and voltage frequency
-Tests capacitance and diodes
| Specification | |||
| AC Current (45 to 400 Hz) | Range | 40.00 A | 400.0 A |
| Resolution | 0.01 A | 0.1 A | |
| Accuracy | 2 % + 10 | 2 % + 5 | |
| AC Voltage (45 to 400 Hz) | Range | 600.0 V | |
| Resolution | 0.1 V | ||
| Accuracy | 1.5% + 5 | ||
| DC Voltage | Range | 600.0 V | |
| Resolution | 0.1 V | ||
| Accuracy | 1% + 5 | ||
| Resistance | Range | 600.0 Ω 6.000 kΩ 60.00 kΩ | |
| Accuracy | 1% + 5 | ||
| Voltage Frequency | Range | 9.999 Hz 99.99 Hz 999.9 Hz 9.999 kHz 99.99 kHz | |
| Accuracy | 0.1% + 3 | ||
| Current Frequency | Range | 45.0 to 400.0 Hz | |
| Accuracy | 0.1% + 3 | ||
| Capacitance | Range | 9.999 uF | 99.99 uF 999.9 uF |
| Accuracy | 2 % + 5 | 5% + 5 | |
| Diode | Range | 3.000 V | |
| Accuracy | 10% | ||
| T-rms Value | – | ||
| Continuity | ● | ||
| Hold | ● | ||
| Backlight | – | ||
| Safety rating | CAT III 300V | ||
| Weight | 132 g | ||
| Size | 190 mm x 52 mm x 16 mm | ||
| Jaw Opening | 34 mm | ||
| Clamp Arm Size | 10 mm X 10 mm | ||
| Battery | (2) AAA Batteries | ||
| Warranty | 1 year | ||
