DWYER TE-TNS Thermowells for Building Automation Temperature Sensors
The Series TE-TNS Stainless Steel Thermowells are used to separate the instrument from the surrounding media. When used with the Series TE and TE-I Immersion Temperature Sensors, further protection is offered from aggressive media, high pressures, and flow rates while allowing for quick and easy installation of temperature sensors without having to drain process media. Thermowells are offered in both 304 and 316 stainless steel allowing for superior corrosion resistance. Fabricated, or welded, thermowells are constructed from a tube that is closed at the tip by a welded solid tip. Solid-machined thermowells are manufactured from barstock.
BENEFITS/FEATURES
• Configurable materials and sizes
• Fabricated (welded) or machined construction
• 1/2˝ or 3/4˝ NPT process connections APPLICATIONS
• Building automation
• Chiller or boiler loops
• Chemical industry or process technology
SPECIFICATIONS
Maximum Pressure: Fabricated: 140 psi; Machined: 304 SS: 3700 psi; 316 SS: 5500 psi.
Maximum Temperature: Fabricated: 1000°F (538°C); Machined: 1200°F (648°C).
Construction: Fabricated (welded) or machined model specific.
