Swahusada is the official distributor of Dwyer in Indonesia. All items on this website are new, and have a direct factory warranty. If you need another type, you can chat with us directly. We serve pre-order and indent purchases for all Dwyer units.
DWYER DUCT AND IMMERSION BUILDING AUTOMATION TEMPERATURE SENSORS
TE-DFN-D1244-00
TE-DFN-D2544-00
TE-ITG-E0844-00
“Sensor type : Pt100 Ω RTD”
The Series TE Duct and Immersion Building Automation Temperature Sensors can be used to monitor air or water temperature throughout a building management system or an air handler unit. Duct or immersion options available with or without an enclosure.
Specification :
Accuracy: Thermistor temperature sensor: ±0.22°C @ 25°C (±0.4°F @ 77°F); RTD
temperature sensor: DIN class A: ±0.15°C @ 0°C (±0.28°F @ 32°F).
Temperature Limits: Operating: -40 to 302°F (-40 to 150°C).
Cable Rating: Plenum option includes UL listed plenum cable.
Housing Material: Meets UL, 94 V-0 polycarbonate plastic.
Housing Rating: NEMA 4X (IP66) (DFW, IBW only).
Weight: 5.3 oz (150.3 g).
Benefits/Features :
• Easy to mount external tab housing and flange options for duct applications
• 1/4 turn housing cover with chain to prevent dropping
• Multiple conduit knockouts for easy installation positioning
• 8″ plenum rated cable option
• Terminal connector eliminates need for wire nuts
Product Application :
• Building automation
• VAV temperature sensing
• Chiller or boiler loops
• AHU monitoring
