Fluke 301B Clamp Meter
The Fluke 301B Clamp Meter has a lightweight and compact body, which allows you to carry it around in your pocket. The slim and thin jaw can easily clamp onto tightly packed wires. The Fluke 301B tests current, voltage, resistance, continuity, frequency (voltage and current), capacitance, and diode, etc.. You can handle more testing needs with it.
Key features :
-The body weighs only 132g and is 16mm thick, which is light and portable and can be fitted into a pocket
-The slim and thin jaw of only 10mm can easily clamp onto tightly packed wires
-600A AC range, 0.01A high resolution
-Tests voltage, resistance and continuity
-Tests current frequency and voltage frequency
-Tests capacitance and diodes
-Backlight
| Specifications | |||
| AC Current (45 to 400 Hz) | Range | 60.00 A | 600.0 A |
| Resolution | 0.01 A | 0.1 A | |
| Accuracy | 2 % + 10 | 2 % + 5 | |
| AC Voltage (45 to 400 Hz) | Range | 600.0 V | |
| Resolution | 0.1 V | ||
| Accuracy | 1.5% + 5 | ||
| DC Voltage | Range | 600.0 V | |
| Resolution | 0.1 V | ||
| Accuracy | 1% + 5 | ||
| Resistance | Range | 600.0 Ω 6.000 kΩ 60.00 kΩ | |
| Accuracy | 1% + 5 | ||
| Voltage Frequency | Range | 9.999 Hz 99.99 Hz 999.9 Hz 9.999 kHz 99.99 kHz | |
| Accuracy | 0.1% + 3 | ||
| Current Frequency | Range | 45.0 to 400.0 Hz | |
| Accuracy | 0.1% + 3 | ||
| Capacitance | Range | 9.999 uF | 99.99 uF 999.9 uF |
| Accuracy | 2 % + 5 | 5% + 5 | |
| Diode | Range | 3.000 V | |
| Accuracy | 10% | ||
| T-rms Value | – | ||
| Continuity | ● | ||
| Hold | ● | ||
| Backlight | ● | ||
| Safety rating | CAT III 300V | ||
| Weight | 132 g | ||
| Size | 190 mm x 52 mm x 16 mm | ||
| Jaw Opening | 34 mm | ||
| Clamp Arm Size | 10 mm X 10 mm | ||
| Battery | (2) AAA Batteries | ||
| Warranty | 1 year | ||
