FLUKE PTI120 Pocket Thermal Imager
The Fluke PTi120 (the Product or Imager) is a handheld, infrared imaging camera for use in many applications. These applications include equipment troubleshooting, preventive and predictive maintenance, building diagnostics, and research and development. The Product shows thermal images on a high-visibility, industrial-quality LCD touch screen. The Product saves images to internal memory which can be transferred to a PC through a direct USB connection to the PC or by wireless transfer to a PC or mobile device. The Product includes Fluke Connect desktop software. Fluke Connect is a high-performance, professional software suite for quality analysis and reporting.
Key features :
• Automatically organize and file thermal images with Fluke Connect Asset Tagging
• Fully radiometric thermal imager gives you measurement data to the pixel with 120 x 90 infrared resolution (10,800 pixels)
• 3.5” LCD touchscreen display for easy troubleshooting
• -20 °C to +150 °C temperature measurement range
• Six color palettes
• Can withstand drop up to 1 meter
• IP 54 enclosure rating
• Subject to Export Control
Specifications :
| Operating range | 0.5 m to 1.2 m |
| Temperature range | -20 °C to 150 °C, Serial number: PTi120-xxxxxxxx -20 °C to 400 °C, Serial number: PTi120H-xxxxxxxx (not calibrated below -10 °C) |
| Accuracy | ±2 °C or 2 % (whichever is greater) |
| Thermal image features | |
| Image capture frequency | 9 Hz |
| Detector resolution | 120 x 90 |
| Total pixels | 10 800 |
| Thermal sensitivity (NETD) | £0.06 °C at 30 °C target temperature (60 mK) |
| Spectral band | 8.0 mm to 14 mm (long wave) |
| Pitch size | 17 mm |
| Field of View (H x V) | 50 ° x 38 ° |
| Spatial resolution (IFOV) | 7.6 mRad |
| F stop number | F1.13 |
| Minimum focus distance | 0.5 m |
| IR-Fusion technology | Adjustable Autoblend™ mode |
| Visual (visible light) features | |
| Operating range | 0.5 m to 3.0 m |
| Resolution | 320 x 240 output |
| Total pixels | 307 200 |
| Field of View (H X V) | 68 ° x 52 ° |
| Focus | Fixed lens |
| Illumination | Yes (On, Off, Illumination) |
| Palette | Grayscale, Ironbow, High Contrast, Amber, Hot Metal, Blue Red |
| Image capture and data storage | |
| Internal storage memory capacity | ~500 images |
| File formats | Non-radiometric (.jpg) or Fully-radiometric (.is2). No analysis software is required for .jpg files. Fluke ConnectTM desktop software is required for .is2 files. |
| Memory review | Thumbnail and full screen review |
| Text annotation | Yes (.is2 file format only, not .jpg file format) |
