Honeywell CO2 Sensor C7233

Swahusada is the official distributor of Honeywell in Indonesia. All items on this website are new, and have a direct factory warranty. If you need another type, you can chat with us directly. We serve pre-order and indent purchases for all Honeywell units.

Honeywell CO2 Sensor C7233

The C7233 Series Sensors are a stand-alone carbon dioxide (CO2) sensors for use in determining ventilation necessity with HVAC controllers. The C7233 measures the CO2 concentration in the occupied space. The C7233 are used in ventilation systems to control the amount of fresh outdoor air supplied to maintain acceptable levels of CO2, and optional temperature sensing.

Features & Benefits:

• Wall mount
• Ultra compact size and elegant design with easy cleaning with smooth front membrane
• Options with or without white LED displays – all variants have red LED notification activated when CO2 level exceeds preset threshold
• Analog output range is selectable 0/2-10 Vdc, 4-20mA and provides accurate proportional linear signal through entire sensing range 0-2000ppm
• Highly accurate and reliable non-dispersion infrared (NDIR) technology for CO2 sensing
• Programmable SPST Relay (1A@50VAC/24VDC)
• Optional temperature output (20K ohm NTC)

Certifications:

• CA Title 24, Part 6
• CEC Standard for Residential and Non-Residential Buildings-2016
• CEC Standard – CO2
