Honeywell V4-BLC-GP16

Swahusada is the official distributor of Honeywell in Indonesia. All items on this website are new, and have a direct factory warranty. If you need another type, you can chat with us directly. We serve pre-order and indent purchases for all Honeywell units.

Honeywell V4-BLC-GP16

The hydronic balance is a significant requirement for the efficient operation of a hydronic heating or cooling installation. In an unbalanced system under or over provision of hot water to individual radiators or circuits can occur. Apart from the correct selection of radiator valves, regulation of individual circuits is also necessary and in some cases, such as DIN 18 380, VOB part C, is required by national standards. This requirement is met with V4 Kombi shutoff and balancing valves. V4 Kombi have functions shut-off, pre-setting and measuring.

Features
• Balancing through stroke limitation with digital pre-setting and visible pre-setting indicator
• Equipped with 2 pressure test cocks for differential pressure measurement
• Non rising spindle with EPDM and EPDM O-ring sealing
• Pre-setting isn’t altered when handwheel is turned
• Regulation screw protected by protection cap
• PTFE seat sealing
• Valve cartridge and spindle made of cast steel
• Available in dimensions up to DN400

Specifications
Flange BS4504 PN16 or ANSI B16.1 Class 125. Other flange types are available.
Operating temperature -10 to 120 °C (14 to 248 °F)
Nominal pressure 16 Bar or 125 Psi
