Honeywell V4BFW16

The V4 Actuated Wafer Type Butterfly Valves are suitable for heating and cooling applications. The V4 series is equipped with standard On-Off or modulating (4~20mA, 1~5V, or 0(2) ~10V select by DIPswitch) control quarter-turn electric actuator.
The V4 series can also provide feedback output signal: Dry contact for On-Off version; 0~5V, 0~10V, 4~20mA (selected by DIP- switch) for modulating version.

Features
• Wide size range (DN 50…DN600 for PN16 type, DN50…DN350 for PN25 type)
• For On-Off or Modulating Control
• Manual override non-clutch design. Manual operation can be operated without any lever, clutch or brake upon power voltage.
• Irreversible worm gear.
• Visual mechanical position indicator for accurate visual reference of valve position.
• Anti-condensation heater and 2 aux. limit switches on standard model
• Enclosure IP67

Specifications
Sizes DN50…DN600 (Wafer Type)
Nominal pressure PN16, PN25
Tightness Bubble tight
