Honeywell V5013 Series

Type N

The V5013N is a three-way threaded globe valve that controls hot water, cold water, and glycol solutions (up to 50 percent concentration) in heating or cooling HVAC applications. The
valve is used for mixing service to direct flow from one of two inlets to a common outlet in two-position or modulating control systems.

Features
• Red brass body with NPT-threaded connections.
• Stainless steel stem and brass plug.
• Low seat leakage rate (≤0.05 percent of Cv).
• Spring-loaded, self-adjusting packing.
• 50:1 rangeability per VDI/VDE 2173.
• Constant total flow throughout full stem travel.
• Accurate positioning to ensure state of the art temperature control.
• Sizes range from 1/2 in. to 2 in.
• Suitable for pneumatic or electric/electronic actuation.
• Repack and rebuild kits available for field servicing.

Models:
V5013N Valve: Three-way mixing valve for water or glycol. NPT-threaded pipe connections. Constant total flow. Push down valve stem to close bottom (B) port.
Approximate Leakage Rate       : 0.05 percent Cv.
Rangeability                                 : 50:1 per VDI/VDE 2173
Pressure-Temperature Ratings:
Water                                             :   36°F to 248°F, 217 psi (15 bar).
248°F to 337°F, 185 psi (12.8 bar).
Maximum Water Differential Pressure: 230 psid (15.8 bar).
Maximum Differential for Quiet Water Service: 20 psid.

Type P

Three port mixing control valves for:
• hot water • chilled water
• Domestic Hot Water in Heating, Ventilating, Air Conditioning Systems, Open Circuits
To be operated by
• electric linear actuators as ML 6420 / 25 ; ML 7420 / 25 ; M 6421 ; M 7421

Features
• Bronze body with BSPT-threaded connections.
• Stainless steel stem and brass plug.
• Low seat leakage rate (≤0.05 percent of Kvs).
• Spring-loaded, self-adjusting packing.
• Accurate positioning to ensure state of the art temperature control.
• Sizes range from 1-1/4 in. to 2 in.

Rangeability              : 50:1
Leakage rate              : ≤0.05% of kvs

Medium temperature and pressure       : Water 2 to 120 °C max. 20 bar
120 to 170 °C max. 12.8 bar
